Tooth overlay in the CAT J250 tooth system

Tooth dimensions:

A: 62 mm

A1: 74 mm

L: 194 mm

H: 86 mm

Weight: 2.9 kg

Caterpillar machines compatible with this part:

WHEELED EXCAVATORS: M315D2 M315 M315GC M313C M313D M314F

RIPPERS: 953B 953 943

WHEEL TRACTOR-SCRAPERS: 613G 613C II 613C

INTEGRATED TOOLCARRIERS: IT18F IT18B IT38G II IT14G2 IT12 IT28 IT18 IT24F IT12B IT14F IT38G IT14G IT14B IT38F IT28G IT28F IT28B

VIBRATORY COMPACTORS: CB-536D

COMPACT WHEEL LOADERS: 914G 914G2

MINI EXCAVATORS: 307C

TRACKED EXCAVATORS: 311D LRR 320C L 316 GC 320-A L 325-A FM L 325B L M315F 312E 312F 320-A S 320-A N 312B 312C 312D 324E 316 GX 325-A M317F 320D2 314D CR 312F GC 311B 313D2 GC 311C 320D L 325 LN 312-A 322B 322C EL240B EL240C 330B L 212B 312B L 320E L 320D2 GC 311-A 325B LN 325D L E240C E240B 326D2 315 313 325 L 206B 326F L 320F L 312D2 L 312C L 313D2-GC 313D2 205B 314E CR 314C 326F 313D2 LGP 324D L E120B 313B 325C 313D 312D2 312D2 GC 312D L 313 GX 322B L 225 325-A LN 313 GC 314D LCR 329D L 317-A 318D2 L 324E L E110B 320 312E L 205 326 206 323 325-A L 329E L 320-A 313F L 330D2 L 212 311F LRR 330F L 317-A N 329E 326D2 L EL200B 314F CR 323 GX 317 N 320N 329F L 315-A 320B 320C 320D 320E 323GC 211B E200B 314E LCR 312 GX 313F LGC 312 GC 320B S 320B N 330F 320B L 316E L 315F LCR 320D2 L M312 M315 323F L 320 L 326F LN

TRACK LOADERS: 939 943 941 939C 953 953B 941B 953C 955L

WHEELED LOADERS: 918F 928G 928HZ G926 916 G916 926 924 930 936 938 G936 930G 930H 930K 930M 924GZ 924HZ 938G II 936E 924F 936F 924H 924G 924K 928F 938G 926E 938F 938H 938K 938M 926M

BACKHOE LOADERS: 450F 450

Catalog number: 1U-3252
