JCB Cylinder Bushing with Graphite (35x45x40mm) - AZERI PARTS
Cylinder bushing with graphite inserts by AZERI PARTS. It was designed specifically for modern JCB mini excavators. Thanks to the use of a bronze alloy matrix and evenly distributed solid graphite lubricant cores, this bushing is characterized by excellent self-lubricating properties.
Key product features:
- Self-lubricating properties: Graphite inserts release solid lubricant under friction, which creates a protective film between the bushing and the pin. This guarantees a longer lifespan of the connection even in the event of a temporary shortage of standard grease.
- High load capacity: The base alloy shows enormous resistance to compression and impact shocks occurring during aggressive digging in hard ground.
Technical Specification:
| Manufacturer |
AZERI PARTS |
|---|
| Component Type |
Sliding bushing / Self-lubricating with graphite inserts |
|---|
| Dimensions (inner x outer x length) |
35 mm x 45 mm x 40 mm |
|---|
Compatibility (JCB Machines):
| Machine Category | Models and Variants |
|---|
| Mini Excavators |
Machines from the 15C - 19E series (e.g., 16C-1, 18Z-1, 19C-1) |
Technical Advice: Bushings with graphite inserts require great care during installation! Under no circumstances should you drive them in directly with a hammer, as shocks can cause the small graphite cores to fall out or micro-cracks in the base material. Always use a proper press fit or a press, ensuring the seat in the arm is clean. Also remember: the term "self-lubricating" does not completely exempt you from maintenance! In severe dusty and muddy conditions, you still need to regularly pump grease through the grease nipples – this is to push out dirt that could penetrate the gap between the pin and the bushing, thus preventing corrosion.
