JCB Injection pump 63kW TC 12V mT3 - DELPHI

320/06934
5,412.00 zł
Tax included

4,400.00 zł tax excl.

1466 1466 By purchasing this product, you will earn points exchangeable for a discount voucher worth 146.60 złfor your next order.

Quantity
Last items in stock

Standard orders are shipped until 14:00. Pallet shipments are dispatched until 13:00.

Unsure? We can select the right part based on the VIN — WhatsApp

Alternative part numbers : 320/06744 320/06848

Description

JCB Fuel Injection Pump 63kW Tier 3 - DELPHI

Brand new, fuel injection pump by DELPHI, dedicated to JCB Dieselmax 444 engines. Product designed for power units with 63kW (approx. 85 HP) equipped with a turbocharger (TC). It is a mechanical pump (mT3 - Mechanical Tier 3) with a "stop" solenoid valve and injection timing advance controlled by 12V. Used in a wide range of JCB construction machinery produced mainly in the years 2005–2026.

Product Features:

  • DELPHI DP System: Proven rotary pump design ensuring precise fuel dosing and easier service compared to Common Rail systems.
  • mT3 Specification: Pump calibrated for Tier 3 emission standards with a mechanical speed governor.
  • Ready to Install: The pump features a locked shaft in the "timing" position (a feature typical for new Delphi pumps), which facilitates synchronization with the timing gear.

Technical Specifications:

Manufacturer DELPHI (For JCB)
Engine Power 63 kW (85 HP)
Control Voltage 12V
Engine Type Dieselmax TC (Turbo), mT3 (Mechanical)

Application (JCB Machines):

Backhoe Loaders 3CX (T3 and T4F versions with mechanical pump)
Compact Loaders (Tracked/Wheeled) 225, 260, 280, MC, 225T, 260T, MCT
Telescopic Handlers 527-58 HC, 527-58 LC
Road Rollers VM75 (Single Drum Vibratory Roller)
Technical Tip: Delphi DP series injection pumps are very sensitive to air locks and contamination. Do not unlock the pump shaft before installing it in the engine! The shaft lock sets the factory injection timing. After mounting the pump into the timing gear, the lock must be released. Before the first start-up, it is necessary to perfectly bleed the low-pressure system (filters, lines) so that the fuel lubricates the pump head from the very first rotations.

Standing by your machine? We'll find the right part in 5 minutes!

Don't waste time searching. Take a picture of the VIN plate or the old part and send it to us on WhatsApp. We will quickly check the catalogs and send you a link to the exact product you need.

Catalog number: 320/06934

Product Details
320/06934

Data sheet

Machine type
BACKHOE LOADER
TELESCOPIC HANDLER
Engine
JCB
Machine
JCB
