JCB Hydraulic tank suction filter - GENUINE

JCB Hydraulic tank suction filter - GENUINE

32/920300
129.84 zł
Tax included

105.56 zł tax excl.

35 35 By purchasing this product, you will earn points exchangeable for a discount voucher worth 3.50 złfor your next order.

Quantity
Available

Standard orders are shipped until 14:00. Pallet shipments are dispatched until 13:00.

Unsure? We can select the right part based on the VIN — WhatsApp
Related products
Photo Title Reference Brand Price
JCB Hydraulic filter - SERVICE FILTERS JCB Hydraulic filter - SERVICE FILTERS 32/926051 SERVICE FILTERS 121.35 zł
JCB Hydraulic filter - SERVICE FILTERS
JCB Hydraulic filter - SERVICE FILTERS
SERVICE FILTERS • 32/926051
121.35 zł

Alternative part numbers :

Description

JCB Hydraulic Tank Suction Filter - ORIGINAL

Original hydraulic tank suction filter (strainer). Designed for the hydraulic system. It is responsible for capturing larger solid contaminants (such as metal shavings, rust, or seal residues) directly from the oil in the tank before it reaches the main hydraulic pump.

Technical Features:

  • Main pump protection: Effectively blocks the entry of particles that could instantly jam spool valves or deeply scratch the precise pumping elements of gear and multi-piston pumps.
  • Optimal flow (No cavitation): The factory-selected density of the filter mesh ensures the free flow of even thick, cold oil. This protects the pump from the destructive phenomenon of cavitation (lack of lubrication and vacuum suction).
  • Reinforced internal structure: A solid, perforated internal frame prevents the filter from collapsing and crushing under the strong suction flow generated by the machine's system.

Compatibility with JCB Machines:

Backhoe Loaders 210/212, 214/215/217, 2CX, 2DX, 3/3C/3CS, 3CX COMPACT, 3CX ENTRY LEVEL (Global), 3CX, 3DX, 4/4C/4CN, 4CX, 4DX, 5CX, MIDI CX
Mini Excavators 45Z, 48Z, 50Z, 51R, 55Z, 56Z, 57C, 60C, 85Z, 86C, 90Z, 100C, 802X, 803X, 804X, 805X, 806X, 808X
Telescopic Handlers (including TM) Telescopic: 512, 513, 530, 540, 555, 558 | TM: TM200, TM300, TM400
Agricultural Tractors AGRIMAX, FASTRAC 7000, FASTRAC 8000
Tracked and Wheeled Excavators Tracked: JS30, JS | Wheeled: HYDRADIG 110W, HYDRADIG 150W
Others (Forklifts, Dumpers, MEWPs) Rough Terrain Forklifts: 926, 930, 940, 950 | Dumpers: 6, 9 TONNE | MEWPs: ELECTRIC SCISSORS (S3246E)
Technical Advice: If you notice that the hydraulic pump has started to operate loudly (a characteristic "whining" under load or even at idle), the first step should be to check the suction filter. A filter clogged with sludge or silicone residues severely restricts the flow. Before installing a new suction filter, drain the old oil and thoroughly clean the bottom of the hydraulic tank from deposits (sludge/scale). When screwing on the filter/cover, always use a new sealing O-ring so that the system does not draw in outside air, which causes oil foaming.

Standing by your machine? We'll find the right part in 5 minutes!

Don't waste time searching. Take a picture of the VIN plate or the old part and send it to us on WhatsApp. We will quickly check the catalogs and send you a link to the exact product you need.

Catalog number: 32/920300

Product Details
32/920300

Data sheet

Machine type
BACKHOE LOADER
FASTRAC
MINIEXCAVATOR
TELESCOPIC HANDLER
Machine
