Main Hydraulic Gear Pump 42 cc/rev (fits JCB) - GMOVE 20/902400
High-quality main hydraulic gear pump by GMOVE with a displacement of 42 cc/rev, dedicated to JCB telescopic handlers. This pump is responsible for powering the entire working hydraulic system – including fast and smooth boom lifting, telescope extension, and attachment handling. Choosing the GMOVE brand guarantees excellent flow parameters, high volumetric efficiency, and long, trouble-free operation even under intensive use in harsh construction and agricultural conditions.
Technical Specification:
- Part type: Main hydraulic gear pump.
- Displacement / Flow rate: 42 cc/rev (flow rate approx. 40 to 80 L/min depending on engine speed).
- Direction of rotation: Counter-Clockwise (CCW).
- Shaft type: Tapered 1:8 (diameter approx. 23 - 25.5 mm).
- Mounting flange: Standard SAE B (mounting hole spacing approx. 101.60 mm).
- Connections (internal threads): Inlet (suction) 1" BSP, outlet (pressure) 3/4" BSP.
- Manufacturer/Brand: GMOVE (high-class replacement compliant with OEM specifications).
JCB Machine Compatibility:
| Machine Category | Series and Models |
|---|
| Telescopic Handlers |
Series: 505, 506, 525, 527, 530, 535, 540 |
Workshop Tip: Replacing the main hydraulic pump in a telehandler is a serious surgical procedure on the hydraulic system. Before installing the new pump, absolutely diagnose the cause of the previous one's failure. If the old pump suffered flaking or seizure, thousands of metallic micro-shavings are floating throughout the entire system (including the tank and hoses). Skipping the thorough system flushing and replacing filters with new ones will lead to immediate scratching and damage to the new pump within the very first minutes of operation!
Before startup: Manually prime the inside of the new pump with fresh, clean hydraulic oil and rotate the shaft several times by hand. This protects the internal thrust plates from a so-called dry start. After starting the machine, let it run for a few minutes at idle speed without load to thoroughly bleed the entire system.
