JCB Cylinder Spring Bushing 40x46x90mm - ORIGINAL
Original spring (tension) cylinder bushing with part number (1207/0019) used in hydraulic cylinder mountings and jaw systems in JCB machines. The 40x46x90 mm bushing acts as a spacer and securing element, eliminating unwanted loosening of pin joints and protecting cylinder seats from wear and tear.
Technical Features:
- Spring Steel: Made of a special steel alloy with high elasticity, allowing for a tight fit in the seat and constant pressure against the walls.
- Original Durability: As a factory JCB product, it features the correct hardness, ensuring it does not crack under sudden impacts or cylinder vibrations.
- Dimensional Consistency: Precise dimensions of 40x46x90 mm guarantee trouble-free installation and secure alignment of the pin.
Technical Specification:
| Inner diameter |
40 mm |
|---|
| Outer diameter |
46 mm |
|---|
| Total length |
90 mm |
|---|
| Part type |
Spring bushing / Original |
|---|
Compatibility with JCB Machines:
| Backhoe Loaders |
1400/1550/1700, 210/212, 214/215/217, 2CX, 3C/3CS, 3CX Compact, 3CX Entry Level, 3CX, 3D, 3DX, 4CX, 4D, 4DX, 5CX |
| Mini Excavators |
802 (1983-1997) |
| Rough Terrain Forklifts |
Full range of models (RTFL series) |
| Telescopic Handlers |
505, 506, 508, 510, 520, 525, 527, 530, 535, 537, 540 |
| Wheel Loaders |
410, 411, 412/412S |
Technical Advice: Spring bushings operate in areas exposed to heavy loads. When replacing the bushing, always clean the inside of the seat from corrosion and old grease to prevent the bushing from cracking during installation. Remember that while the spring bushing itself does not require constant lubrication like plain bushings, the pin operating inside it should be clean and protected from seizing.
