JCB Pin Bolt Spacer Bushing - AZERI PARTS
Spacer bushing by AZERI PARTS, designed for securing and correctly seating pin bolts and bosses in JCB machinery. This element plays a key role in eliminating axial play and ensuring the precise assembly of working components.
Key Product Features:
- Mechanical Durability: Material resistant to variable dynamic loads occurring during boom operation.
- Dimensional Precision: Strict adherence to diameter tolerances ensures a perfect bolt fit and pin stabilization.
- Connection Protection: Prevents mounting boss wear by evenly distributing clamping forces.
Technical Specification:
| Manufacturer |
AZERI PARTS |
|---|
| Outer Diameter (OD) |
25 mm |
|---|
| Inner Diameter (ID) |
13 mm |
|---|
Application (JCB Telescopic Handlers):
Loadall Series: 505, 506, 507, 509, 510, 512, 525, 526, 527, 530, 531, 535, 536, 540, 541, 542, 550
Technical Advice: Always check the condition of spacer bushings when replacing working pins. Even a slight deformation of the bushing can lead to uneven clamping force on the locking bolt, which consequently causes accelerated wear of the loader arm bosses. Before installation, it is recommended to clean the contact surfaces of corrosion and old grease.
