Alternator by +LINE used in JCB machines, it provides stable power supply to all electrical components and effective battery charging in 24-volt systems. Made from durable materials, it is resistant to overloads, vibrations, and high temperatures, ensuring long-lasting and trouble-free operation under demanding field conditions.

Voltage: 24V

Amperage: 70A

Pulley with overrunning clutch: no

Mounting holes: 3

Position (°): 0

JCB Machines:

WHEEL LOADERS: 414S; variants: 414S, .414S, 416S; variants: 416S, .416S, 426; variants: 426, .426, 426E; variants: 426E (Loading Shovel), .426E (Loading Shovel), 434S; variants: 434S, .434S, 436; variants: 436, .436, 436E; variants: 436E (Loading Shovel), .436E (Loading Shovel), 446; variants: 446, .446, 456; variants: 456, .456, 456E; variants: 456E (Loading Shovel), .456E (Loading Shovel), 714; variants: 714, .714, 718; variants: 718, .718, 722; variants: 722 (TIER 3), .722

Used in other machines:

AES: 16201226
ATLAS: 6089167, 6162529
CUMMINS: 2874863, 3972735, 4003446, 4936879, 4993343, 5282841, CU5282841
DELCO REMY: 10459274, 10459372, 15502489, 19011004, 19011005, 19011010, 19011014, 19011015, 19011019, 8600017, 860001712B1, 8600020, 8600154, 8600360, 8600407, 8600504, 8600505, 8700019
DIXIE: 10124201, A1701
HC-CARGO: 116317, F032116317
HYSTER: 4020872
INGERSOLL-RAND: 22616965
JCB: 333E5501, 71440388, 71440473, 71440537
LUCAS: LEA0763, LRA03812, LRA3812
NEW HOLLAND: 82827042
PSH: 706504070
RNL: RNL8600017
UNIPOINT: ALT3800
WAI: 8709N, 8709R, 8715N
WILSON: 90014466, 90014466N
WOOD AUTO: ALT40023, ALT40185, REM8600017, WOOALT40023, WOOALT40185

Catalog number: 714/40388
