JCB Transmission Oil Filter - ORIGINAL
Original transmission oil filter dedicated to the drivetrains of JCB machinery. Designed to effectively remove solid contaminants such as metal shavings or deposits that form during gearbox operation. The use of a high-performance filtration medium ensures oil cleanliness, which protects solenoid valves, clutch discs, and the transmission pump from premature wear.
Significant product advantages:
- Control System Protection: Effective filtration prevents valve sticking in Powershift and Synchro Shuttle type transmissions.
- Durable Construction: The reinforced filter housing is resistant to sudden oil pressure spikes, guaranteeing system tightness.
- Precise Fit: The 1"-12UNF thread and standard dimensions allow for quick and reliable replacement during periodic servicing.
Technical Specification:
| Manufacturer |
JCB |
|---|
| Height |
117 mm |
|---|
| Outer Diameter |
96 mm |
|---|
| Thread |
1"-12UNF |
|---|
Wide Application (JCB Machines):
Backhoe Loaders: 3CX (all versions), 4CX, 5CX, 3DX, 210, 214, 215, 217
Telescopic Handlers: models from 506 to 560 (including 531, 535, 540, 541, 542)
TM Loaders: TM 200, TM 300, TM 400
Site Dumpers: 6 Tonne, 9 Tonne
Transmissions: Powershift (PS), Synchro Shuttle (SS), Transfer Gearbox (TG)
Technical Advice: Regular replacement of the transmission oil filter (in accordance with the JCB service schedule) is essential to maintain proper control pressure in the gearbox. Before installing a new filter, lubricate the gasket with clean transmission oil and tighten it by hand until it makes contact with the base, then perform an additional half turn.
