PARKER 3-section hydraulic pump

PARKER 3-section hydraulic pump

7049532007
7,134.00 zł
Tax included

5,800.00 zł tax excl.

1933 1933 By purchasing this product, you will earn points exchangeable for a discount voucher worth 193.30 złfor your next order.

Quantity
Last items in stock

Standard orders are shipped until 14:00. Pallet shipments are dispatched until 13:00.

Unsure? We can select the right part based on the VIN — WhatsApp

Alternative part numbers :

Description

Triple Section Hydraulic Pump - PARKER

Original, high-performance triple section gear pump by Parker, designed for the most demanding power hydraulic systems. Thanks to three independent sections with varying displacements, the pump allows for simultaneous supply to multiple working circuits (e.g., steering system, working arm, and attachments) while maintaining optimal pressure parameters.

Key Product Advantages:

  • Multi-section Efficiency: The 40 + 33 + 16 cm³/rev configuration allows for precise distribution of oil flow according to the machine's requirements.
  • SAE B-B Standard: 1" splined shaft with 15 teeth ensures reliable torque transfer and resistance to overloads.
  • Solid Parker Construction: Cast housing with a weight of 38 kg guarantees excellent vibration damping and long service life in heavy-duty operating conditions.

Technical Specification:

Manufacturer PARKER
Pump Type Gear, triple section
Section Displacement 40 + 33 + 16 cm³/rev
Drive Shaft 1" (15 teeth), SAE B-B
Mounting Flange SAE B (4 mounting holes)
Net Weight ~38 kg
Technical Advice: Before installing a new pump, it is mandatory to replace the hydraulic filter and check the cleanliness of the oil in the reservoir. During installation, ensure that the pump's rotation direction matches the machine's drive. The initial startup should be performed with the system bled to avoid cavitation and premature wear of the gear components.

Standing by your machine? We'll find the right part in 5 minutes!

Don't waste time searching. Take a picture of the VIN plate or the old part and send it to us on WhatsApp. We will quickly check the catalogs and send you a link to the exact product you need.

Catalog number: 7049532007

Product Details
7049532007

Data sheet

Hydraulic pump type
GEAR
Machine
JCB
