JCB Motor Starter 12V 4,2KW - PLUS LINE

320/09346
922.50 zł
Tax included

750.00 zł tax excl.

250 250 By purchasing this product, you will earn points exchangeable for a discount voucher worth 25.00 złfor your next order.

Quantity
Available

Standard orders are shipped until 14:00. Pallet shipments are dispatched until 13:00.

Unsure? We can select the right part based on the VIN — WhatsApp

Alternative part numbers : 320/09452 320/09452 320/09144 320/09035 320/09032 320/09026 320/09022

Description


Starter Motor 4.2kW for JCB - Plus Line (320/09346)

High-performance Plus Line Starter Motor, reference number 320/09346. This is a heavy-duty 4.2 kW unit, designed specifically for JCB Dieselmax engines. With superior torque output, the Plus Line starter ensures fast and reliable cranking even in freezing conditions, outperforming standard 3.0 kW models.

Why choose Plus Line Starters?

  • Powerful Cranking: 4.2 kW power output provides high cranking speed essential for diesel engines.
  • Durability: Sealed housing protects internal components from construction dust and moisture.
  • Efficiency: Planetary gear reduction design reduces battery drain while maximizing torque.

Technical Specification:

JCB Part Number 320/09346, 32009346
Brand Plus Line (High Performance)
Voltage / Power 12V / 4.2 kW
Drive Pinion 11 Teeth / CW Rotation
Compatibility
(Selected Models)		 Backhoe Loaders: 3CX, 4CX, 5CX (All series incl. Eco/Super).
Telescopic Handlers: 531-70, 535-95, 535-125, 535-140, 540-140, 540-170, 541-70, 550-80.
Wheeled Excavators: Hydradig 110W.
Site Dumpers: 6T, 7T, 9T, 10T.
Other: VM Rollers, TM320 Loaders, Generators (G-Series).
Cross References JCB: 320/09022, 320/09032, 320/09035, 320/09144, 320/09409, 320/09454
Mahle: MS84, AZF4186, AZF4576, 11131711
Lucas: LRS02489, LRS2489
Expert Tip: Starting issues? Before replacing the starter, check the engine ground strap and ignition switch contacts. Corroded connections often mimic the symptoms of a failed starter motor.

Standing by your machine? We'll find the right part in 5 minutes!

Don't waste time searching. Take a picture of the VIN plate or the old part and send it to us on WhatsApp. We will quickly check the catalogs and send you a link to the exact product you need.

Catalog number: 320/09346

Product Details
320/09346

Data sheet

Machine type
BACKHOE LOADER
Machine
JCB
