Professional rubber track by Arisun, size 300x55.5x82 in Y version. Strictly dedicated to Yanmar mini excavators (VIO and B series). Distinguished by a unique 55.5 mm pitch and an asymmetric design, essential for the proper functioning of these Japanese undercarriages.
| Width: | 300 mm |
| Pitch: | 55.5 mm |
| Links: | 82 pcs |
| Version: | Y (Asymmetric Yanmar) |
Manufactured using Continuous Cord Technology. The Y designation indicates an asymmetric steel core layout (offset) and external guiding. This design is specifically developed to prevent the track from rubbing against the machine frame in Yanmar models where the undercarriage is tucked close to the body.
The 300x55.5x82Y track is dedicated to Yanmar and select Komatsu machines:
✅ YANMAR VIO: VIO30 (select years), VIO30-1, VIO30-2, VIO30-3, VIO30V, VIO33, VIO35, VIO35-1, VIO35-2, VIO35-3, VIO35-5, VIO35CR, VIO38
✅ YANMAR B SERIES: B27, B27-2, B27-2B, B27V, B30, B30V, B30VCR, B30VPR, B37, B37-2, B37-2B, B37V, B37VCR, B3
✅ KOMATSU: PC30FR-2 (Check pitch! Some versions vary)
⬇️ Don't see your machine here? A full, detailed list of all compatible models can be found in the table at the very bottom of the page.
The Y symbol designates an asymmetric track dedicated to Yanmar equipment. Its guide lugs are not centered but offset to the side, which is required by the undercarriage design of these machines. Most 300 mm tracks have a 52.5 mm pitch. Yanmar uses a unique 55.5 mm pitch. Installing a track with the wrong pitch will cause the sprocket teeth to misalign with the links, destroying the track in hours. What does the Y symbol mean?
Why is the 55.5 mm pitch important?
Don't waste time searching. Take a picture of the VIN plate or the old part and send it to us on WhatsApp. We will quickly check the catalogs and send you a link to the exact product you need.
| Brand | Model |
|---|---|
| KOMATSU | PC30FR.2 |
| YANMAR | B27.2B |
| YANMAR | B27V |
| YANMAR | B3.3 |
| YANMAR | B30V |
| YANMAR | B30VCR |
| YANMAR | B30VPR |
| YANMAR | B35 |
| YANMAR | B37.2B |
| YANMAR | B37V |
| YANMAR | B37VCR |
| YANMAR | B37VPR |
| YANMAR | VIO30.1 |
| YANMAR | VIO30.2 |
| YANMAR | VIO30.3S |
| YANMAR | VIO30V |
| YANMAR | VIO33 |
| YANMAR | VIO35.1 |
| YANMAR | VIO35.2 |
| YANMAR | VIO35.3 |
| YANMAR | VIO35.5 |
| YANMAR | VIO35CR |
| YANMAR | VIO38 |
| YANMAR | VIO38U |
ARISUN is a manufacturer of rubber tracks for excavators and mini-excavators, designed for heavy-duty operation in challenging ground conditions. A reinforced steel core combined with a high-resistance rubber compound provides stability, reliable traction, and extended service life of the undercarriage system.
ARISUN rubber tracks are compatible with popular machine brands such as JCB, KOMATSU, KUBOTA, BOBCAT, TAKEUCHI, VOLVO, CAT, CASE, JOHN DEERE, YANMAR — depending on the selected track size. They perform well in earthmoving applications, trenching, construction work, road maintenance, municipal operations, and general site conditions, ensuring smooth machine movement even on soft or muddy terrain.
