Rubber Track 230x96x38 – Standard 1.5-2.0t (Long Pitch)
Professional rubber track by Arisun, size 230x96x38. This is a universal size used in mini excavators ranging from 1.5 to 2.2 tons. This track is a structural equivalent to the popular size 230x48x76, offering the same mounting parameters using "Long Pitch" technology.
| Width: |
230 mm |
| Pitch: |
96 mm |
| Links: |
38 pcs |
Manufactured using Continuous Cord Technology. With fewer links (38 instead of 76), the track is stiffer and more resistant to stretching in rough terrain, while maintaining full compatibility with drive systems designed for a 48mm pitch.
Key Technical Advantages:
- Versatility: Fits most 1.5-2.0t machines running on 230 mm wide tracks.
- Reinforced Weight: Arisun tracks are approx. 10% heavier than standard aftermarket options, translating to thicker tread and longer service life.
- Self-Cleaning: Tread design facilitates mud removal, which is crucial when working in soft terrain.
Wide Compatibility (Brands & Models)
The 230x96x38 track (interchangeable with 230x48x76) fits a wide range of machines:
✅ JCB: 801, 801.4, 801.5, 801.6, 8014, 8015, 8016, 8017, 8018 (Super/CTS), 8020, 8020 CTS, 8020 ZTS, Micro Plus
✅ WACKER NEUSON: 1903, 2203, 1903RD, 2203RD, ET18, ET20
✅ KOBELCO: SK015, SK20SR, SK020SR
✅ GEHL: 193, 223, GE193, GE223
✅ MUSTANG: ME1903, ME2203
✅ HINOWA: HP1500, HP1500/2
✅ CATERPILLAR (CAT): 302.2D (check length, sometimes 230x48x76)
✅ EUROCOMACH: ES150, ES180
✅ KOMATSU: PC14R-2, PC16R-2 (check width, often 230mm)
⬇️ Don't see your machine here? A full, detailed list of all compatible models can be found in the table at the very bottom of the page.
Service Tip: When installing a new track, always inspect the undercarriage. Running a new track on a worn
drive sprocket or damaged idler will drastically shorten the track's lifespan.
Frequently Asked Questions (FAQ)
Can it replace a 230x48x76 track?
Yes. The 230x96x38 track is a "Long Pitch" version which replaces the "Short Pitch" 230x48x76 version. The difference is that one 96mm link replaces two 48mm links. The total length is identical, and the drive sprocket fits perfectly (engaging every other tooth).
Does it fit every JCB 8018?
Yes, for the vast majority of JCB 8018 models (CTS, Super). This is the standard size for this machine. Just ensure your old track width is 230 mm.
Catalog number: 230X96X38
ARISUN is a manufacturer of rubber tracks for excavators and mini-excavators, designed for heavy-duty operation in challenging ground conditions. A reinforced steel core combined with a high-resistance rubber compound provides stability, reliable traction, and extended service life of the undercarriage system.
ARISUN rubber tracks are compatible with popular machine brands such as JCB, KOMATSU, KUBOTA, BOBCAT, TAKEUCHI, VOLVO, CAT, CASE, JOHN DEERE, YANMAR — depending on the selected track size. They perform well in earthmoving applications, trenching, construction work, road maintenance, municipal operations, and general site conditions, ensuring smooth machine movement even on soft or muddy terrain.
