Rubber Track 300x52.5x74N – Narrow Guide Version
Professional rubber track by Arisun, size 300x52.5x74 in N version. Dedicated to mini excavators in the 2.5-ton range. This version features narrow internal guiding (Narrow Guide), which is a specific requirement for undercarriages in machines like Bobcat X325/328 series, Hanix, and Neuson.
| Width: |
300 mm |
| Pitch: |
52.5 mm |
| Links: |
74 pcs |
| Version: |
N (Narrow Guide) |
Manufactured using Continuous Cord Technology. The N designation indicates narrowed guide lugs. Using this track on the machines listed below (e.g., Bobcat X325) is necessary to avoid tensioning issues and de-tracking that occur with the W version.
Key Technical Advantages:
- Type N (Narrow Guide): Precisely matched to track rollers in older and mid-range Bobcat and Hanix models.
- Reinforced Weight: Arisun tracks are approx. 10% heavier than standard aftermarket options, resulting in a thicker tread and more robust steel cord.
- Pro-Edge Technology: Optimized side edges reduce the risk of mechanical damage when climbing obstacles.
Wide Compatibility (Brands & Models)
The 300x52.5x74N track fits the following machine models:
✅ BOBCAT: X325, X328, X328E
✅ HANIX: H22A, H24, H26B, H27, N220-2, N230-2, N230-2R, N250-2, N260-2, N260-2R, N26B, NS25
✅ NEUSON: 2600, 2600RD, 2702, 2702RD, 2702RD SLR, 2800, 2902, 2902RD FORCE
✅ SCHAEFF: HR24, HR27, HR4A
✅ HYUNDAI: ROBEX 28.5, ROBEX 28.7
✅ DAEWOO / DOOSAN: Solar 25
✅ FIAT HITACHI: FH22 PLUS
✅ OTHERS: Ausa MH25, Cams 225S, Dynapac VD251, Eurocomach ES300, Eurotom TS27S, Libra 125S/212T2, Vermeer D20X22
⬇️ Don't see your machine here? A full, detailed list of all compatible models can be found in the table at the very bottom of the page.
Service Tip: When installing a new track, always inspect the undercarriage. Running a new track on a worn
drive sprocket or damaged idler will drastically shorten the track's lifespan.
Frequently Asked Questions (FAQ)
What is the difference between N and W versions?
The N (Narrow) symbol indicates narrow internal guiding. This is crucial for machines like Bobcat X325 or Hanix H26, which have a specific roller spacing. The W (wide) version is designed for different undercarriage types.
Does it fit Bobcat 331?
Usually not. The Bobcat 331 typically requires a track with 80 or 84 links (N or W versions). This track has 74 links and is designed for smaller models like the X325 or X328.
Catalog number: 300X52,5X74N
ARISUN is a manufacturer of rubber tracks for excavators and mini-excavators, designed for heavy-duty operation in challenging ground conditions. A reinforced steel core combined with a high-resistance rubber compound provides stability, reliable traction, and extended service life of the undercarriage system.
ARISUN rubber tracks are compatible with popular machine brands such as JCB, KOMATSU, KUBOTA, BOBCAT, TAKEUCHI, VOLVO, CAT, CASE, JOHN DEERE, YANMAR — depending on the selected track size. They perform well in earthmoving applications, trenching, construction work, road maintenance, municipal operations, and general site conditions, ensuring smooth machine movement even on soft or muddy terrain.
