Rubber Track 230x48x70 – For 1.5-1.8 Ton Mini Excavators
Professional rubber track by Arisun, size 230x48x70. This is a popular size for mini excavators with an operating weight of approx. 1.5-1.8 tons. This track (Short Pitch) is often used interchangeably with the 230x96x35 version (Long Pitch), offering a smoother ride due to closer link spacing.
| Width: |
230 mm |
| Pitch: |
48 mm |
| Links: |
70 pcs |
Manufactured using Continuous Cord Technology. The short pitch (48 mm) ensures that each link engages smoothly with the drive sprocket, reducing vibrations transmitted to the operator and the machine's undercarriage. This is particularly important for precise finishing work.
Key Technical Advantages:
- Ride Comfort: The Short Pitch design significantly reduces vibrations during travel compared to Long Pitch versions.
- Reinforced Weight: Arisun tracks are approx. 10% heavier than standard aftermarket options, translating to a more solid build.
- Versatility: Fits many machine models, including popular Hitachi ZX, Kubota U, and Takeuchi TB series.
Wide Compatibility (Brands & Models)
The 230x48x70 track fits the following models:
✅ HITACHI: ZX17, ZX17U-2, ZX17U-2 YLR, ZX17U-5, ZX18-3, ZX19U-5
✅ KUBOTA: U15, KX41-2 (SV/VC versions), KX41-3 (V version), RX141
✅ TAKEUCHI: TB15F, TB15FR, TB215 Long-Evo, TB219
✅ KOMATSU: PC15MR-1, PC15MRX, PC16R-2, PC18
✅ CATERPILLAR: 301.5 (CR/REG), 301.8 (C/CD)
✅ HYUNDAI: Robex 16-9, Robex 17Z-9A
✅ TEREX: TC19
✅ HINOWA: TT1600, TT1700
✅ IHI: 15NX, 18J, 18N, IS16J, IS18J
✅ OTHERS: Daewoo Solar 015 Plus, Ditch Witch MX182, Eurocomach ES180ZT, Furukawa FX014UR, Hanix H17D, Sumitomo SH18J, Sunward SWE18U
⬇️ Don't see your machine here? A full, detailed list of all compatible models can be found in the table at the very bottom of the page.
Service Tip: When installing a new track, always inspect the undercarriage. Running a new track on a worn
drive sprocket or damaged idler will drastically shorten the track's lifespan.
Frequently Asked Questions (FAQ)
Can it replace a 230x96x35 track?
Yes. The 230x48x70 (Short Pitch) track is a replacement for the 230x96x35 (Long Pitch) track. Two 48mm links correspond to one 96mm link. The short-pitch version (offered here) ensures less vibration during travel.
Does it fit every Hitachi ZX17?
Yes, most ZX17 models (including U-2, U-5 versions) run on tracks of this length. However, it is always worth checking if your machine has a standard tensioner installed.
Catalog number: 230X48X70
ARISUN is a manufacturer of rubber tracks for excavators and mini-excavators, designed for heavy-duty operation in challenging ground conditions. A reinforced steel core combined with a high-resistance rubber compound provides stability, reliable traction, and extended service life of the undercarriage system.
ARISUN rubber tracks are compatible with popular machine brands such as JCB, KOMATSU, KUBOTA, BOBCAT, TAKEUCHI, VOLVO, CAT, CASE, JOHN DEERE, YANMAR — depending on the selected track size. They perform well in earthmoving applications, trenching, construction work, road maintenance, municipal operations, and general site conditions, ensuring smooth machine movement even on soft or muddy terrain.
