Rubber Track 230x72x41 – For Mini Excavators and Dumpers
Professional rubber track by Arisun, size 230x72x41. This is a specialized size used in mini excavators and tracked dumpers with an operating weight of approx. 1.0-1.2 tons. It features a unique link count (41 pcs), which is crucial for proper tensioning in Yanmar and Atlas machines.
| Width: |
230 mm |
| Pitch: |
72 mm |
| Links: |
41 pcs |
Manufactured using Continuous Cord Technology. Thanks to a solid steel cord wrap and a reinforced rubber compound, this track withstands dynamic loads well, typical for tracked dumpers carrying heavy loads.
Key Technical Advantages:
- Dedicated Size: Perfectly matched to Yanmar C6R dumpers and Atlas 110 mini excavators, where the standard 43 links would be too loose.
- Reinforced Weight: Arisun tracks are approx. 10% heavier than standard aftermarket options, increasing puncture resistance.
- Versatility: Performs well in difficult terrain (mud, sand) thanks to a universal tread pattern.
Wide Compatibility (Brands & Models)
The 230x72x41 track fits the following machines:
✅ YANMAR: B158, C6R, C06R (tracked dumpers)
✅ ATLAS: 110, 1104, CT100, CT100R, CT150, CT150R, CT200R
✅ IHI: 12, IS12 (select versions)
✅ BONNE ESPERANCE: Microsandy
⬇️ Don't see your machine here? A full, detailed list of all compatible models can be found in the table at the very bottom of the page.
Service Tip: When installing a new track, always inspect the undercarriage. Running a new track on a worn
drive sprocket or damaged idler will drastically shorten the track's lifespan.
Frequently Asked Questions (FAQ)
Can it replace a 230x72x43 track?
Not always. The 230x72x41 track is two links shorter (14.4 cm). If your tensioner has a large adjustment range, you might be able to fit it, but in most cases, it will be too short. Always match the link count to the original.
Does it fit dumpers?
Yes, this size is dedicated to machines like the Yanmar C6R dumper. The reinforced Arisun track structure handles heavy load transport perfectly.
Catalog number: 230X72X41
ARISUN is a manufacturer of rubber tracks for excavators and mini-excavators, designed for heavy-duty operation in challenging ground conditions. A reinforced steel core combined with a high-resistance rubber compound provides stability, reliable traction, and extended service life of the undercarriage system.
ARISUN rubber tracks are compatible with popular machine brands such as JCB, KOMATSU, KUBOTA, BOBCAT, TAKEUCHI, VOLVO, CAT, CASE, JOHN DEERE, YANMAR — depending on the selected track size. They perform well in earthmoving applications, trenching, construction work, road maintenance, municipal operations, and general site conditions, ensuring smooth machine movement even on soft or muddy terrain.
