Rubber Track 230x96x32 – For 1.5-1.7 Ton Mini Excavators
Professional rubber track by Arisun, size 230x96x32. This is a specialized size used in modern Kubota mini excavators as well as many IHI and Hinowa machines. This track features 32 links with a 96 mm pitch (Long Pitch), making it an equivalent to the short-pitch version with 64 links (230x48x64).
| Width: |
230 mm |
| Pitch: |
96 mm |
| Links: |
32 pcs |
Manufactured using Continuous Cord Technology. With fewer links, the track is lighter and more flexible, making it perfect for light, agile machines working in tight spaces. Increased cut resistance (Heavy Duty) ensures long service life even on rocky terrain.
Key Technical Advantages:
- Perfect Fit: Tailored for popular Kubota KX series and Hinowa machines.
- Reinforced Structure: Arisun tracks are approx. 10% heavier than standard aftermarket options, translating to a more robust cord and thicker tread.
- Stability: The Long Pitch design reduces the risk of de-tracking during sharp maneuvers.
Wide Compatibility (Brands & Models)
The 230x96x32 track fits the following models:
✅ KUBOTA: KX015-4, KX016-4, KX36-3, KX41-2SC, KX41-3S, KX41-3SGL
✅ HINOWA: DM15, DM15M, PT15G, VT1550, VT1650
✅ IHI: 14NXT, 15J, 16N, 17J, 17JE, 17N, 17NE, IS15J, IS16N, IS17J, IS17JE
✅ EUROCOMACH / EUROTRAC: E1500, HT150
✅ IMER: 16NX
✅ SUMITOMO: SH15J
✅ MESSERSI: M18BE/C
✅ OTHERS: ATN Piaf 450, Terramite TX15
⬇️ Don't see your machine here? A full, detailed list of all compatible models can be found in the table at the very bottom of the page.
Service Tip: When installing a new track, always inspect the undercarriage. Running a new track on a worn
drive sprocket or damaged idler will drastically shorten the track's lifespan.
Frequently Asked Questions (FAQ)
Can it replace a 230x48x64 track?
Yes. The 230x96x32 track is a "Long Pitch" version which replaces the "Short Pitch" 230x48x64 track. One 96mm link replaces two 48mm links. If your drive sprocket is not worn, installation is seamless.
Does it fit Kubota KX41-3?
Yes, but it depends on the version. S and SGL versions of the KX41-3 often use this track (32 links). Other versions may require a different length. Always count the links on your old track.
Catalog number: 230X96X32
ARISUN is a manufacturer of rubber tracks for excavators and mini-excavators, designed for heavy-duty operation in challenging ground conditions. A reinforced steel core combined with a high-resistance rubber compound provides stability, reliable traction, and extended service life of the undercarriage system.
ARISUN rubber tracks are compatible with popular machine brands such as JCB, KOMATSU, KUBOTA, BOBCAT, TAKEUCHI, VOLVO, CAT, CASE, JOHN DEERE, YANMAR — depending on the selected track size. They perform well in earthmoving applications, trenching, construction work, road maintenance, municipal operations, and general site conditions, ensuring smooth machine movement even on soft or muddy terrain.
