JCB Drive sprocket (Premium Quality) - GMOVE

JCB Drive sprocket (Premium Quality) - GMOVE

331/42641
467.40 zł
Tax included

380.00 zł tax excl.

126 126 By purchasing this product, you will earn points exchangeable for a discount voucher worth 12.60 złfor your next order.

Quantity
Last items in stock

Standard orders are shipped until 14:00. Pallet shipments are dispatched until 13:00.

Unsure? We can select the right part based on the VIN — WhatsApp
Related products
Photo Title Reference Brand Price
JCB Motor reducer/final drive JCB Motor reducer/final drive 333/K0684 AM 9,717.00 zł
JCB Motor reducer/final drive
JCB Motor reducer/final drive
AM • 333/K0684
9,717.00 zł

Alternative part numbers :

Description

JCB JS200 / JS220 / JS260 Drive Sprocket (Premium) – GMOVE

High-class drive sprocket by GMOVE, dedicated to the most popular JCB tracked excavators in the 18-26 ton class. This Premium version is characterized by the number of mounting points (22 holes), which is typical for reinforced final drives used in Heavy Duty and T3 versions. Thanks to precise induction hardening, the sprocket teeth exhibit extreme abrasion resistance, ensuring a long service life for the undercarriage even in difficult rocky conditions.

Product Features:

  • 22-Hole Standard: Dedicated to specific types of hydraulic motors (final drives), ensuring perfect torque transmission without the risk of shearing studs.
  • Deep Hardening: The heat treatment process covers not only the tooth surface but also its base, protecting against fatigue cracks under heavy loads.
  • Manufacturing Precision: The 403 mm inner diameter is perfectly matched to the hub, facilitating assembly and centering the sprocket relative to the track frame.

Technical Specifications:

Number of Teeth 21
Number of Mounting Holes 22
Inner Diameter 403 mm
Quality Premium / GMOVE

Application (JCB Tracked Excavators):

JS Series (18-26t) JS 180, JS 190, JS 200, JS 200 T3, JS 210, JS 210 T3, JS 220, JS 235, JS 240, JS 260
Special Versions XD (Extra Duty), HD (Heavy Duty), LR (Long Reach) – e.g. JS220 XD, JS260 XD
JZ Series (Zero Tail) JZ 225
Technical Tip: In the JS200-JS260 class of excavators, manufacturers used various types of final drives (e.g., Kayaba, Bonfiglioli, Hy-Dash), which differ in the number of holes on the hub (versions with 20, 22, or 24 bolts exist). Before purchasing, be sure to count the number of bolts on your machine. This sprocket features 22 holes. Before installation, thoroughly clean the contact surface between the hub and the sprocket to avoid axial runout, which can lead to bolt loosening.

Standing by your machine? We'll find the right part in 5 minutes!

Don't waste time searching. Take a picture of the VIN plate or the old part and send it to us on WhatsApp. We will quickly check the catalogs and send you a link to the exact product you need.

Catalog number: 331/42641

Product Details
331/42641

Data sheet

Machine type
EXCAVATOR
Machine
JCB
