Track Tensioner (Premium) JCB JS / X Series - GMOVE
High-class track tensioner by GMOVE, part number 332/J3048. This Premium version product is designed for modern JCB JS series tracked excavators and the latest X series. This key undercarriage component is responsible for maintaining proper track chain tension, which translates to smooth machine operation and minimizes the risk of throwing a track in difficult terrain. Made from hardened steel alloys, resistant to extreme compressive forces and corrosive conditions.
Product Features:
- Reinforced Seals: A special sealing package protects the tensioner cylinder from mud and sand ingress, preventing grease leaks and tension loss.
- Precision Piston: The chrome-plated piston rod surface ensures minimal friction and high corrosion resistance, guaranteeing smooth adjustment.
- Undercarriage Protection: A properly functioning GMOVE tensioner effectively absorbs impacts from the front idler, protecting the undercarriage frame and final drive from damage.
Technical Specifications:
| JCB Part Number |
332/J3048 |
|---|
| Component Type |
Track Tensioner (Cylinder) |
|---|
| Application |
Tracked Undercarriage |
|---|
| Quality |
Premium / GMOVE |
|---|
Application (JCB Tracked Excavators):
| X Series |
131X, 140X, 145XR, 150X |
|---|
| JS Series |
JS 130, JS 131, JS 145 |
|---|
| JZ Series (Zero Tail) |
JZ 140, JZ 141 |
|---|
Technical Tip: A faulty tensioner (grease leak) is the most common cause of tracks coming off in the field. When installing a new tensioner, we recommend thoroughly cleaning the spring seat and checking the condition of the grease valve. Remember not to tension the track "too tight" – proper tension (according to the machine's manual) is essential to avoid premature wear of the chain and final drive bearings.
