JCB DIPPER Arm Perforated Bushing (46x48.3x38mm) - 829/30941
Perforated bushing for the excavator dipper arm, designed for JCB mini and tracked excavators. The characteristic perforations (grease holes and dimples) are designed to retain lubricant and ensure its optimal distribution across the working surface. This significantly reduces friction, prevents seizing, and extends the lifespan of both the bushing and the mating pin under heavy loads.
Technical Specification:
- Element type: Perforated bushing.
- Internal diameter: 46 mm.
- External diameter: 48.3 mm.
- Width / Length: 38 mm.
- Application: DIPPER arm joints.
Compatibility:
| Machine Type | Models and Series |
|---|
| Mini Excavators |
802, 802X, 803, 803X, 804, JCB 30Plus |
| Tracked Excavators (JS) |
JS 30, JS 30 [T3], JS 30 (2013 - 2014) |
Workshop Technical Advice: When installing a perforated bushing, alignment is critical. If the housing has a specific grease channel, ensure that the lubrication holes in the bushing perfectly align with it. Misalignment can block the flow of fresh grease, causing the joint to work dry and leading to rapid, catastrophic wear of the pin and bushing. Due to its relatively thin walls, never use a direct hammer blow to install it; always use a suitable press or a properly sized flat drift tool to press it in evenly without deforming the edges.
