Upper Kingpin Sliding Bearing Bush (fits JCB) - AM 333/D1561
High-quality upper kingpin sliding bearing bush by AM (Aftermarket) for JCB telescopic handlers. This is a precision component of the steering and axle system, fitted in the upper bore of the steering knuckle where it acts as a plain bearing for the kingpin. Its purpose is to guide the kingpin with minimal friction, absorb lateral axle loads and ensure precise, play-free rotation of the steering knuckle during cornering. Manufactured from a high-quality alloy with graphite or PTFE (Teflon) additives, it offers excellent wear resistance and outstanding self-lubricating properties — extending the service life of the entire kingpin assembly. AM Aftermarket grade — full interchangeability with the OEM part, precise fit without modification.
Technical Specification:
| Part Type |
Upper kingpin sliding bearing bush |
|---|
| Parts Category |
Steering System / Axle / Steering Knuckle |
|---|
| Part Number |
333/D1561 |
|---|
| Mounting Position |
Upper |
|---|
| Inner Diameter (ID) |
44.8 mm (≈ 45 mm) |
|---|
| Outer Diameter (OD) |
74.9 mm (≈ 75 mm) |
|---|
| Height (thickness) |
22.1 mm (≈ 22 mm) |
|---|
| Quality |
AM (Aftermarket) |
|---|
Application (JCB Machines):
| Telescopic Handlers |
512 Series, 513 Series, 550 Series, 555 Series (5.5), 558 Series, 560 Series |
|---|
Workshop Technical Tip: Worn kingpin bushes show up as noticeable wheel wobble when pushed up-down or sideways, a metallic knock over rough ground and a vague, imprecise steering feel. Always replace the full set — upper and lower together — uneven wear between a new and old bush will rapidly destroy the new one. Bushes are pressed into the knuckle bore with an interference fit — never drive them in with a hammer directly; always use a press or a correctly sized driver. Before fitting a new kingpin, measure its diameter for ovality — a kingpin outside tolerance will destroy new bushes within hours. After assembly, grease the nipples with fresh grease and steer lock-to-lock several times to distribute grease evenly through the bushes.
