JCB Final Drive Gearbox (Reduction Unit) - 333/K0684
High-quality final drive planetary gearbox (travel reduction unit) designed for JCB crawler excavators. This offer includes only the mechanical section of the gearbox, ready for assembly with an existing hydraulic motor. The component features precision-engineered planetary carriers and hardened ring gears, ensuring smooth transmission of high torque to the drive sprocket.
Technical Specification:
- Number of frame mounting holes: 30.
- Number of sprocket mounting holes: 22.
- Sprocket pilot diameter: 403 mm.
- Type: Multi-stage planetary gearbox (mechanical).
- Design: Input socket prepared for standard JCB travel motor splines.
- Compatybile hydraulic motor catalog number: 332/H3935
Compatibility:
| Machine Series | Models |
|---|
| JCB Excavators |
JCB205, JCB215, JCB225, JCB245 |
| JS Excavators |
JS 160, JS 180, JS 190, JS 200, JS 205, JS 210, JS 220, JS 235, JS 240, JS 260 |
| JZ Excavators |
JZ 235, JZ 255 |
Workshop Technical Advice: When mounting the gearbox section to an old hydraulic motor, it is essential to check the condition of the motor's output shaft. If the motor splines are worn, they will quickly damage the input socket in the new reduction unit. Remember to replace the seal between the motor and the gearbox and to fill the gearbox with fresh gear oil. Never run the drive "dry" after motor assembly.
