Rubber Track 230x48x66 – Most Popular Standard 1.5-1.7t
Professional rubber track by Arisun, size 230x48x66. This is the most widely used track size for mini excavators with an operating weight of 1.5 to 1.7 tons. Manufactured using "Short Pitch" technology (48mm pitch), it ensures significantly greater operator comfort compared to the long-pitch version.
| Width: |
230 mm |
| Pitch: |
48 mm |
| Links: |
66 pcs |
Manufactured using Continuous Cord Technology. Thanks to the dense link arrangement (66 links), the track wraps smoothly around the drive sprocket, eliminating the machine "bouncing" effect during travel. It is a fully compatible replacement for 230x96x33 tracks.
Key Technical Advantages:
- Ride Comfort (Short Pitch): Denser links reduce vibrations by up to 30% compared to Long Pitch versions, which is crucial for long working hours.
- Reinforced Weight: Arisun tracks are approx. 10% heavier than standard aftermarket options, translating to a thicker tread and more robust cord.
- Maximum Versatility: Fits 90% of 1.5-ton mini excavators on the market.
Wide Compatibility (Brands & Models)
The 230x48x66 track fits a huge number of machines:
✅ BOBCAT: 320, 322, 323, E16, X320, X322, X323
✅ CATERPILLAR (CAT): 301.5, 301.6, 301.8, 301.6C, 301.8C
✅ JCB: 8014, 8015, 8016, 8017, 8018 (check if not 230x96x38), Micro Plus
✅ VOLVO: EC15, EC15B, EC15C, EC15XR, EC15XT
✅ KUBOTA: KX36, KX36-2, KX41, KX41-2 (S/V), RX141
✅ HITACHI: EX15, EX15-2, EX16, EX17, ZX16, ZX18
✅ TEREX / SCHAEFF: TC16, HR11, HR12, HR13
✅ KOBELCO: SK15, SK17, SK015
✅ DAEWOO / DOOSAN: Solar 015, Solar 15
✅ PEL-JOB: EB12.4, EB14, EB150, EB16, Sirius Plus
✅ CASE: 15, 16, CX15, CX16
✅ NEUSON: 1403, 1404, 1501, 1502, 1503 (check width, can be 250mm)
✅ HANIX: H15, H15B, N150-2
⬇️ Don't see your machine here? A full, detailed list of all compatible models can be found in the table at the very bottom of the page.
Service Tip: When installing a new track, always inspect the undercarriage. Running a new track on a worn
drive sprocket or damaged idler will drastically shorten the track's lifespan.
Frequently Asked Questions (FAQ)
Can it replace a 230x96x33 track?
Yes! The 230x48x66 (Short Pitch) track is a replacement for the 230x96x33 (Long Pitch) track. Two 48mm links replace one 96mm link. The short-pitch version (offered here) ensures significantly better operating comfort (less vibration).
What is the difference between 230x48x66 and 230x48x62?
The difference is the track length (4 links = approx. 19 cm). The 66-link version fits most 1.5t machines (Bobcat 320, CAT 301.5), while the 62-link version is designed for slightly smaller/shorter undercarriages (e.g., Komatsu PC16, Hitachi ZX14). They are not interchangeable.
Catalog number: 230X48X66
ARISUN is a manufacturer of rubber tracks for excavators and mini-excavators, designed for heavy-duty operation in challenging ground conditions. A reinforced steel core combined with a high-resistance rubber compound provides stability, reliable traction, and extended service life of the undercarriage system.
ARISUN rubber tracks are compatible with popular machine brands such as JCB, KOMATSU, KUBOTA, BOBCAT, TAKEUCHI, VOLVO, CAT, CASE, JOHN DEERE, YANMAR — depending on the selected track size. They perform well in earthmoving applications, trenching, construction work, road maintenance, municipal operations, and general site conditions, ensuring smooth machine movement even on soft or muddy terrain.
