Rubber Track 230x96x33 – Standard 1.5-1.8t (Long Pitch)
Professional rubber track by Arisun, size 230x96x33. This is one of the most sought-after sizes for mini excavators weighing 1.5-1.8 tons. Manufactured using "Long Pitch" technology, this track is a direct and fully compatible replacement for 230x48x66 tracks.
| Width: |
230 mm |
| Pitch: |
96 mm |
| Links: |
33 pcs |
Manufactured using Continuous Cord Technology. With half the number of links (33 instead of 66) compared to the short-pitch version, this track offers greater lateral stiffness and resistance to twisting, which is crucial when working on uneven terrain.
Key Technical Advantages:
- Universal Replacement: Fits machines factory-equipped with both 33-link (96mm) and 66-link (48mm) tracks.
- Reinforced Weight: Arisun tracks are approx. 10% heavier than standard aftermarket options, ensuring a thicker tread and longer service life.
- Pro-Edge Technology: Specially reinforced side edges protect against damage when driving over curbs and rubble.
Wide Compatibility (Brands & Models)
The 230x96x33 track fits a very wide range of machines:
✅ BOBCAT: 320, 321, 322, 323, E16, X320, X322, X323
✅ CATERPILLAR (CAT): 301.5, 301.6, 301.7D, 301.8, 301.4C, ME15, MM15
✅ JCB: 8014, 8015, 8016, 8017, 8018 (check version, some require 230x96x38)
✅ VOLVO: EC15, EC15B, EC15C, EC15XT, EC13
✅ HITACHI: EX15, EX16, EX17, ZX16, ZX18
✅ KOBELCO: SK15, SK17, SK015
✅ TEREX / SCHAEFF: TC16, HR11, HR12, HR13
✅ NEUSON: 1403, 1404, 1503, 1703, 1903 (check width, sometimes 250mm)
✅ DAEWOO / DOOSAN: Solar 015, Solar 15
✅ HANIX: H15, N150
✅ CASE: 15, 16, CX15, CX16
✅ FIAT HITACHI: FH16.2, FH17.2
⬇️ Don't see your machine here? A full, detailed list of all compatible models can be found in the table at the very bottom of the page.
Service Tip: When installing a new track, always inspect the undercarriage. Running a new track on a worn
drive sprocket or damaged idler will drastically shorten the track's lifespan.
Frequently Asked Questions (FAQ)
Can it replace a 230x48x66 track?
Yes. The 230x96x33 track is a "Long Pitch" version which is a direct replacement for the "Short Pitch" 230x48x66 version. The drive sprocket fits perfectly (engaging every other tooth), and the total length is identical.
Does it fit Bobcat 320?
Yes, this is the standard size for most years of Bobcat 320, 322, and 323. However, it's always worth checking the width (230 mm) and counting the links on the old track to avoid confusion with rare versions.
Catalog number: 230X96X33
ARISUN is a manufacturer of rubber tracks for excavators and mini-excavators, designed for heavy-duty operation in challenging ground conditions. A reinforced steel core combined with a high-resistance rubber compound provides stability, reliable traction, and extended service life of the undercarriage system.
ARISUN rubber tracks are compatible with popular machine brands such as JCB, KOMATSU, KUBOTA, BOBCAT, TAKEUCHI, VOLVO, CAT, CASE, JOHN DEERE, YANMAR — depending on the selected track size. They perform well in earthmoving applications, trenching, construction work, road maintenance, municipal operations, and general site conditions, ensuring smooth machine movement even on soft or muddy terrain.
