JCB Gear annulus ring 66T - GENUINE

JCB Gear annulus ring 66T - GENUINE

450/10205
798.27 zł
Tax included

649.00 zł tax excl.

216 216 By purchasing this product, you will earn points exchangeable for a discount voucher worth 21.60 złfor your next order.

Quantity
Available

Standard orders are shipped until 14:00. Pallet shipments are dispatched until 13:00.

Unsure? We can select the right part based on the VIN — WhatsApp
Related products
Photo Title Reference Brand Price
JCB Carrier annulus JCB Carrier annulus 450/12702 AM 196.80 zł
JCB Final drive housing/cover - AZERI PARTS JCB Final drive housing/cover - AZERI PARTS 458/M4232 Azeri Parts 822.43 zł
JCB Carrier annulus
JCB Carrier annulus
AM • 450/12702
196.80 zł
JCB Final drive housing/cover - AZERI PARTS
JCB Final drive housing/cover - AZERI PARTS
Azeri Parts • 458/M4232
822.43 zł
Show all related products ↓

Alternative part numbers :

Description

JCB 66T Wheel Hub Ring Gear - ORIGINAL

Original wheel hub ring gear (planetary annulus gear) with 66 internal teeth. This part constitutes the outer, stationary element of the planetary gear in the machine's final drive. It cooperates directly with the planetary gears (pinions), enabling the reduction of rotational speed and the multiplication of torque transmitted to the wheels.

Technical Features and Parameters:

  • Number of teeth: 66T (internal teeth).
  • Dimensions: Outer diameter: approx. 260 mm | Inner diameter: approx. 225 mm | Height: approx. 75 mm.
  • High abrasion resistance: Made of forged and then precisely surface-hardened steel. This guarantees resistance to tooth breakage under the powerful torsional forces generated when pushing material or working in heavy terrain.
  • Compatibility: The milled tooth profile prevents excessive noise (final drive whining) and premature wear of the mating planetary gears.

Compatibility with JCB Machines:

Backhoe Loaders 210/212, 214/215/217, 2CX, 3/3C/3CS, 3CX COMPACT, 3CX ENTRY LEVEL (Global), 3CX, 3D/3DS, 3DX, 4/4C/4CN, 4CX, 4D, 4DX, 5CX
Telescopic Handlers 504, 505, 506, 507, 508, 509, 510, 512, 514, 520, 523, 525, 526, 527, 528, 530, 531, 532, 533, 535, 536, 537, 538, 540, 541, 542, 550, 560
Wheel Loaders (including TM) Wheel Loaders: 410, 411, 412/412S, 413/413S, 417HT, 418/418S | TM: TM 200, TM 300
Agricultural Tractors FASTRAC 1000, FASTRAC 2000, FASTRAC 3000
Wheeled and Tracked Excavators Wheeled: HYDRADIG 110W (including Pothole Pro, STV, T4F, UN3, T4) | Tracked: JS 260, JS260 [T3]
Rough Terrain Forklifts and Dumpers Forklifts: 926, 930, 940, 945, 950 | Dumpers: 6, 7, 9 TONNE
Technical Advice: Damage to the ring gear teeth is most often a chain reaction resulting from the grinding of the final drive planetary gears or the sun gear on the axle shaft. Never replace the ring gear alone if the mating planetary gears show signs of pitting, breakage, or excessive sharp wear – the old, worn component will instantly destroy the new part. Before installing the new ring gear, you must absolutely perfectly clean the axle housing and hub of metal shavings. The remaining "silver" in the oil will act like an abrasive paste and destroy the tapered roller hub bearings.

Standing by your machine? We'll find the right part in 5 minutes!

Don't waste time searching. Take a picture of the VIN plate or the old part and send it to us on WhatsApp. We will quickly check the catalogs and send you a link to the exact product you need.

Catalog number: 450/10205

Product Details
450/10205

Data sheet

Machine type
BACKHOE LOADER
EXCAVATOR
TELESCOPIC HANDLER
WHEELED LOADER
Machine
JCB
